Характеристики Power Supply ATX 1000W Chieftec PROTON BDF-1000C, 80+ Bronze, 140mm, Active PFC, DC/DC, Full Modular
Brand: Chieftec
Produce:
.
Model Proton 1000W
Article no. BDF-1000C
EAN code 4,71071E+12
Weight (without/with package) 2.58 kg / 3.08 kg
AC Input 100-240V / 15.0A
Frequency 50-60Hz
+5V 23A
+3.3V 23A
+5V & +3.3V combined 140W
+12V 1 996W / 83.0A
P.F. >0.9
-12V 0.5A / 6.0W
+5VsB 3.0A / 15W
Maximum Power 1000W
20+4 PIN ATX 1
8 PIN EPS (4+4) 1
8 PIN EPS 1
8 PIN PCIe (6+2) 6
SATA 9
MOLEX 3
FLOPPY 1
24PIN ATX 500
8 PIN EPS (4+4) 550
8 PIN EPS 550
8 PIN PCIe (6+2) 3x 500/150
SATA 3x 450/150/150
MOLEX 450/150/150/150
FLOPPY Molex
Specification ATX 12V 2.3
Form factor PS II
Efficiency 80 PLUS® Bronze
Dimension (DxWxH) 160mm x 150mm x 87mm
PFC Active PFC (0.9)
Fan 140mm silent fan
Security AFC (Automatic Fanspeed Control)
OCP (Overcurrent Protection)
OPP (Overload Protection)
OTP (Over Temperature Protection)
OVP (Overvoltage Protection)
SCP (Short-circuit Protection)
SIP (Surge & Inrush Protection)
UVP (Undervoltage Protection)
